HAMCO70 DISTILLATION TEST APPARATUS AS PER ASTM D 86

Test Method:

The sample is evaporated and condensed under controlled conditions, and observations are made of the temperatures at which various percentages are recovered and/or the percentages recovered at specified temperatures.

STANDARD : Conforms to the specifications of:

ASTM D86, D285, D4737 and related international specifications

  • TYPE OF HEAING :- ELECTRICALLY HEATED HEATER
  • MAX WORKING TEMPERATURE :- 400 DEGREE C
  • CONTINOUS WORKING TEMPERATURE :- 350 DEGREE C
  • CAPACITY :- 1 SAMPLE AT A TIME.
  • HEATER :- CERAMIC COIL HEATER
  • INPUT POWER SUPPLY : 230 V AC, 50 HZ, 1 PHASE WITH 8 AMP CURRENT RATING.
  • HEATING LOAD : 1 KW .
  • FLASK ADJUSTMENT : BY MANUAL CAM MECHANISAM/ RACK & PINION ARRANGEMENT
  • COOLING BATH : MADE OF STAINLESS STEEL WITH DRAIN CORK.
  • COOLING BATH STAND : MS STAND , DULY POWDERCOATED
  • DISTILLATION FLASK : MADE OF CORNING GLASS , CAPACITY 125ML .
  • MEASURING CYLINDER : MADE OF CORNING GLASS WITH GRADUATION DONE AS PER CLASS A CERTIFICATE.
  • SIDE ARM CORK : MADE OF SILICON TO WITHSTAND HIGH TEMPERATURE.
  • TOP ARM CORK : MADE OF SILICON TO WITHSTAND HIGH TEMPERATURE AND TO MOUNT THERMOMETER.
  • ASTM 7C UPTO 300 DEGREE C
  • ASTM 8C UPTO 400 DEGREE C
  • DOUBLE WALLED CONSTRUCTION , THERMALLY INSULATED WITH INSIDE BODY MADE OF STAINLESS STEEL OUTSIDE GI.
  • POWDER COATED EXTERNAL SURFACE FOR ESTHATIC APPEARANCE.

ACCESSORIES WILL BE SUPPLID WITH EQUIPMENT :-

  • DISTILLATION FLASK — 1 NO(CAT NO HAMCO 30AC1)
  • MEASURING CYLINDER — 1 NO (CAT NO HAMCO 30AC2)
  • SIDE ARM CORK — 1 NO (CAT NO HAMCO 30AC3)
  • TOP ARM CORK – 1 NO. (CAT NO HAMCO 30AC4)
  • THERMOMETER ASTM 7C — 1 NO. (CAT NO HAMCO 30AC5)
  • THERMOMETER ASTM 8C – 1 NO. (CAT NO HAMCO 30AC6)

SPARES REQUIRED FOR 5 YEAR TROUBLE FREE OPERATION :-

  • DISTILLATION FLASK — 6 NO(CAT NO HAMCO 19AC1)
  • MEASURING CYLINDER — 6 NO (CAT NO HAMCO 19AC2)
  • SIDE ARM CORK — 3 NO (CAT NO HAMCO 19AC3)
  • TOP ARM CORK – 3 NO. (CAT NO HAMCO 19AC4)
  • THERMOMETER ASTM 7C — 3 NO. (CAT NO HAMCO 19AC5)
  • THERMOMETER ASTM 8C – 3 NO. (CAT NO HAMCO 30AC6)
  • ASBESTOS PAD BIG HOLE – 3 NO ( CAT NO HAMCO 19S1)
  • ASBESTOS PAD SMALL HOLE (CAT NO HAMCO 19S2)
  • HEATER – 3 NO ( CAT NO HAMCO 19S3)

ELECTRICAL REQUIREMENT –

  • 220-240V, 50/60Hz, Single Phase, 8.0A
  • OR 115V, 50/60Hz, Single Phase, 16.0A

DIMENSION :-

  • L x W x H in (cm) 16”x21.5”x14.5” (41x55x37)
  • Net Weight: 64 lbs (29kg)

SHIPPING INFORMATION :

  • Shipping Weight: 78 lbs (35kg)
  • Dimensions: 8.2 Cu. ft.

Ordering Information:

CATALOGUE NO PRODUCT DESCRIPTION ELECTRICAL REQUIREMENT
HAMCO 70 DISTILLATION APPARATUS 220-240V, 50/60Hz, 10.8 AMP
HAMCO 70EXP DISTILLATION APPARATUS 115V, 50/60Hz,20.8 AMP
