HAMCO18D AUTOMATIC DIGITAL ABEL FLASH POINT APPARATUS AS PER IP 170



TEST METHOD :- Flash Point is Lowest temperature at which application of the ignition source causes the vapour of a specimen of the sample to ignite under the specified condition of the test.

The temperature of the approximately 70 ml test specimen is increased rapidly at first and then at a slower constant rate as the flash point is approached. At specified intervals a test flame is passed across the cup, to measure the tendency of the test specimen to form a flammable mixture with air under controlled laboratory conditions.

STANDARD :- Conforms to the specifications of:

ISO 13736/ IP 170, ISO 1516, ISO 1523

  • Range: -10 to +100 deg C.
  • Test Method: ISO 13736/ IP 170, ISO 1516, ISO 1523
  • Ignition Source: Electrical ignitor with LPG gas
  • Temperature Sensor: PT-100 in stainless steel
  • Flash Detector: CRC
  • Controller: Touch Screen, Colour Display with PLC with audio visual alarm to check the 3-wire RTD temperature sensor, free potential flame detector sensor as i/p. with automatic barometric reading correction.
  • Heating is done by metal block with external
  • Inbuilt storage memory for Flash
  • Flame-Sampling Arrangement: 10 Rpm, C. 12 v or 24V DC, gear motor, vertical movement reciprocating to & fro motion.
  • Heater: 800 W,
  • Electrical ignition flame-sampling. Ignition transformer having continuous o/p of 6 Kv. D.C. from 230 v A.C. i/p.
  • Equipment Overall Size (LxWxH): 280mm (W) X 530mm ( D ) X 415 mm ( H )
  • Equipment Gross Weight: 22
  • Equipment supply will be 230 V Ac, 50 Hz with 15 amp

Features:-

Single Action Setting: – The Flash Detection sensor and temperature sensor are permanently mounted on a lid, which allows easy setting of the specimen.

Easy Operation: – Select a Test Mode and enter the expected flash Point. While instrument executes the test, you are free to do other lab work. The tester follows the exact procedures prescribed in the test method and the completion of the test cycle is signalled by buzzer. The test result is brightly shown in VFD and same will be stored in the HMI.

Automatically Shut The Machine And Horn The Buzzer In The Case:

1 EFP+30oC or at 100oC is reached
2 Temperature sensor is found defective
3 Flash detector is found defective
4 LPG solenoid is working
5 Stirrer not working
6 Heater has gone
7 Side Ignition coil/solenoid has gone



Installation Site: Temperature: 0 to 45 degree C, Humidity: Less Than 90% (No condensation).

Utility:

  • Power Supply 230 V Ac, 16
  • GAS Supply (LP Gas or Natural Gas Pressure Less than 8 Kpa) in case of gas fired.

Accessories Will Be Supplied With Equipment:-

  • Abel Cup & Lid — 1 No (Cat No Hamco18ac1)
  • Thermal Printer — 1 No (Cat No Hamco30ac7)
  • Thermal Printer Roll — 1 No (Cat No Hamco30ac8)
  • Pc Interface Cable 1 (Cat No Hamco30ac9)
  • Software For Above– 1 (Cat No Hamco30ac10)
  • Thermal Fuse 1 (Cat No Hamco30ac5)
  • Signal Cable – 1 ( Cat No Hamco 30ac6)

Spares Required For 5 Year Trouble Free Operation:-

  • Ceramic Heater — 2 (Cat No Hamco30s1)
  • Thermal Insulator — 1 (Cat No Hamco30s2)
  • Abel Cup With Lid — 2 (Cat No Hamco30ac1)
  • Ignitor Coil 3 No Each (Cat No Hamco30s3)
  • Cooling Fan 1 (Cat No Hamco30s4)
  • Thermal Printer Roll 5 No ( Cat No Hamco30ac8)

Electrical Requirement

  • 220-240V, 50/60Hz, Single Phase, 9A
  • OR 115V, 50/60Hz, Single Phase,8A

Dimension: – Ixwxh, in.(cm) 11x22x17 (28x53x41)

Net Weight: 49 lbs (22kg)

Shipping Information:- Shipping Weight: 78 lbs (35kg) Dimensions: 4.7 Cu. ft.

Ordering Information:-

Catalogue No Product Description Electrical Requirement
Hamco 18D Automatic Abel Flash Point Apparatus 220-240v, 50/60hz
Hamco 18D Exp Automatic Abel Flash Point Apparatus 115v, 50/60hz
Hamco 30S1 Ceramic Heater
Hamco 30S2 Thermal Insulator
Hamco 30AC1 Pensky Martene Cup With Lid
Hamco 19S3 Ignitor Coil
Hamco 19S4 Cooling Fan
Hamco 19AC8 Thermal Printer Roll





  • Selection Guide Coming Soon
